代号 PART NO. |
螺 纹 THREAD |
O形圈 O-RING |
尺 寸 DIMENSIONS |
||||||
|
|
E |
F |
E端 |
|
A |
B |
L |
S1 |
|
|
1FN-04-02 |
9/16″×18 |
Z1/8″×27 |
O011 |
|
9.8 |
10.5 |
26.5 |
17 |
|
|
1FN-04 |
9/16″×18 |
Z1/4″×18 |
O011 |
|
9.8 |
15 |
30.5 |
17 |
|
|
1FN-04-06 |
9/16″×18 |
Z3/8″×18 |
O011 |
|
9.8 |
16 |
30.5 |
19 |
|
|
1FN-06-04 |
11/16″×16 |
Z1/4″×18 |
O012 |
|
11.2 |
15 |
32 |
19 |
|
|
1FN-06 |
11/16″×16 |
Z3/8″×18 |
O012 |
|
11.2 |
16 |
33.5 |
19 |
|
|
1FN-06-08 |
11/16″×16 |
Z1/2″×14 |
O012 |
|
11.2 |
19.5 |
39 |
24 |
|
|
1FN-08-04 |
13/16″×16 |
Z1/4″×18 |
O014 |
|
12.8 |
15 |
36 |
22 |
|
|
1FN-08-06 |
13/16″×16 |
Z3/8″×18 |
O014 |
|
12.8 |
16 |
36.5 |
22 |
|
|
1FN-08 |
13/16″×16 |
Z1/2″×14 |
O014 |
|
12.8 |
19.5 |
40 |
24 |
|
|
1FN-08-12 |
13/16″×16 |
Z3/4″×14 |
O014 |
|
12.8 |
19.5 |
42.5 |
30 |
|
|
1FN-10-08 |
1″×14 |
Z1/2″×14 |
O016 |
|
15.5 |
19.5 |
45 |
27 |
|
|
1FN-10-12 |
1″×14 |
Z3/4″×14 |
O016 |
|
15.5 |
19.5 |
45 |
30 |
|
|
1FN-12-08 |
1.3/16″×12 |
Z1/2″×14 |
O018 |
|
17 |
19.5 |
46.5 |
32 |
|
|
1FN-12 |
1.3/16″×12 |
Z3/4″×14 |
O018 |
|
17 |
19.5 |
47 |
32 |
|
|
1FN-12-16 |
1.3/16″×12 |
Z1″×11.5 |
O018 |
|
17 |
25.5 |
53.5 |
36 |
|
|
1FN-16-12 |
1.7/16″×12 |
Z3/4″×14 |
O021 |
|
17.5 |
19.5 |
48 |
38 |
|
|
1FN-16 |
1.7/16″×12 |
Z1″×11.5 |
O021 |
|
17.5 |
25.5 |
53.5 |
38 |
|
|
1FN-16-20 |
1.7/16″×12 |
Z1.1/4″×11.5 |
O021 |
|
17.5 |
26.5 |
57 |
46 |
|
|
1FN-20-16 |
1.11/16″×12 |
Z1″×11.5 |
O025 |
|
17.5 |
