代号 PART NO. |
螺 纹 THREAD |
|
尺 寸 DIMENSIONS |
||||||||||||||||
|
|
E |
F |
|
|
A |
B |
L |
S1 |
|
||||||||||
|
1JN-02 |
5/16″×24 |
Z1/8″×27 |
|
|
11.4 |
10.5 |
28 |
12 |
|
||||||||||
|
1JN-04-02 |
7/16″×20 |
Z1/8″×27 |
|
|
14 |
10.5 |
30.5 |
12 |
|
||||||||||
|
1JN-04 |
7/16″×20 |
Z1/4″×18 |
|
|
14 |
15 |
35 |
17 |
|
||||||||||
|
1JN-04-06 |
7/16″×20 |
Z3/8″×18 |
|
|
14 |
16 |
36 |
19 |
|
||||||||||
|
1JN-04-08 |
7/16″×20 |
Z1/2″×14 |
|
|
14 |
19.5 |
41.5 |
24 |
|
||||||||||
|
1JN-05-04 |
1/2″×20 |
Z1/4″×18 |
|
|
14 |
15 |
35 |
17 |
|
||||||||||
|
1JN-05-06 |
1/2″×20 |
Z3/8″×18 |
|
|
14 |
16 |
36 |
19 |
|
||||||||||
|
1JN-05-08 |
1/2″×20 |
Z1/2″×14 |
|
|
14 |
19.5 |
41.5 |
24 |
|
||||||||||
|
1JN-06-04 |
9/16″×18 |
Z1/4″×18 |
|
|
14.1 |
15 |
34.5 |
17 |
|
||||||||||
|
1JN-06 |
9/16″×18 |
Z3/8″×18 |
|
|
14.1 |
16 |
36 |
19 |
|
||||||||||
|
1JN-06-08 |
9/16″×18 |
Z1/2″×14 |
|
|
14.1 |
19.5 |
41.5 |
24 |
|
||||||||||
|
1JN-08-04 |
3/4″×16 |
Z1/4″×18 |
|
|
16.7 |
15 |
39 |
22 |
|
||||||||||
|
1JN-08-06 |
3/4″×16 |
Z3/8″×18 |
|
|
16.7 |
16 |
40 |
22 |
|
||||||||||
|
1JN-08 |
3/4″×16 |
Z1/2″×14 |
|
|
16.7 |
19.5 |
44 |
24 |
|
||||||||||
|
1JN-08-12 |
3/4″×16 |
Z3/4″×14 |
|
|
16.7 |
19.5 |
46.5 |
30 |
|
||||||||||
|
1JN-10-06 |
7/8″×14 |
Z3/8″×18 |
|
|
19.3 |
16 |
43.5 |
24 |
|
||||||||||
