BSPT MALE

代号

PART NO.

螺 纹  THREAD

尺 寸  DIMENSIONS

E

F

A

B

L

S1

1T-02SP

R1/8″×28

R1/8″×28

10

10

26

12

1T-02-04SP

R1/8″×28

R1/4″×19

10

14.5

30.5

14

1T-02-06SP

R1/8″×28

R3/8″×19

10

15

31

17

1T-04SP

R1/4″×19

R1/4″×19

14.5

14.5

34

14

1T-04-06SP

R1/4″×19

R3/8″×19

14.5

15

35

17

1T-04-08SP

R1/4″×19

R1/2″×14

15

20

43

22

1T-06SP

R3/8″×19

R3/8″×19

15

15

36

17

1T-06-08SP

R3/8″×19

R1/2″×14

15

20

43

22

1T-08SP

R1/2″×14

R1/2″×14

20

20

46

22

1T-08-12SP

R1/2″×14

R3/4″×14

20

20

48

27

1T-12SP

R3/4″×14

R3/4″×14

20

20

48

27

1T-12-16SP

R3/4″×14

R1″×11

20

25.5

55.5

36

1T-16SP

R1″×11

R1″×11

25.5

25.5

61

36

1T-16-20SP

R1″×11

R1.1/4″×11

25.5

26.5

64.5

46

1T-20SP

R1.1/4″×11

R1.1/4″×11

26.5

26.5

65.5

46

1T-20-24SP

R1.1/4″×11

R1.1/2″×11

26.5

26.5

67

50

1T-24SP

R1.1/2″×11

R1.1/2″×11

26.5

26.5

67

50

1T-24-32SP

R1.1/2″×11

R2″×11

26.5

30

71.5

65

1T-32SP

R2″×11

R2″×11

30

30

75

65
