PART NO. |
THREAD E |
HOSE BORE |
|
DIMENSIONS |
|||||
|
|
|
DN |
DASH |
|
A |
C |
S1 |
|
|
|
15611-02-03 |
Z1/8″×27 |
5 |
03 |
|
21.5 |
10.5 |
12 |
|
|
|
15611-02-04 |
Z1/8″×27 |
6 |
04 |
|
22.5 |
10.5 |
12 |
|
|
|
15611-04-03 |
Z1/4″×18 |
5 |
03 |
|
27 |
15 |
17 |
|
|
|
15611-04-04 |
Z1/4″×18 |
6 |
04 |
|
28 |
15 |
17 |
|
|
|
15611-04-05 |
Z1/4″×18 |
8 |
05 |
|
28 |
15 |
17 |
|
|
|
15611-04-06 |
Z1/4″×18 |
10 |
06 |
|
28 |
15 |
17 |
|
|
|
15611-06-04 |
Z3/8″×18 |
6 |
04 |
|
28 |
16 |
19 |
|
|
|
15611-06-05 |
Z3/8″×18 |
8 |
05 |
|
29 |
16 |
19 |
|
|
|
15611-06-06 |
Z3/8″×18 |
10 |
06 |
|
29 |
16 |
19 |
|
|
|
15611-06-08 |
Z3/8″×18 |
12 |
08 |
|
30.5 |
16 |
19 |
|
|
|
15611-08-06 |
Z1/2″×14 |
10 |
06 |
|
34 |
19.5 |
22 |
|
|
|
15611-08-08 |
Z1/2″×14 |
12 |
08 |
|
34.5 |
19.5 |
22 |
|
|
|
15611-08-10 |
Z1/2″×14 |
16 |
10 |
|
35.5 |
19.5 |
22 |
|
|
|
15611-12-08 |
Z3/4″×14 |
12 |
08 |
|
37.5 |
19.5 |
27 |
|
|
|
15611-12-10 |
Z3/4″×14 |
16 |
10 |
|
37.5 |
19.5 |
27 |
|
|
|
15611-12-12 |
Z3/4″×14 |
20 |
12 |
|
38.5 |
19.5 |
27 |
|
|
|
15611-12-16 |
Z3/4″×14 |
25 |
16 |
|
39.5 |
19.5 |
32 |
|
|
|
15611-16-10 |
Z1″×11.5 |
16 |
10 |
|
45 |
25.5 |
36 |
|
|
|
15611-16-12 |
Z1″×11.5 |
20 |
12 |
|
45 |
25.5 |
36 |
|
|
|
15611-16-16 |
Z1″×11.5 |
25 |
16 |
|
46.5 |
25.5 |
36 |
|
|
|
15611-20-16 |
Z1.1/4″×11.5 |
25 |
16 |
|
49 |
26.5 |
46 |
|
|
|
15611-20-20 |
Z1.1/4″×11.5 |
32 |
20 |
|
50.5 |
26.5 |
46 |
|
|
|
15611-24-24 |
Z1.1/2″×11.5 |
40 |
24 |
|
51 |
27.5 |
50 |
|
|
|
15611-32-32 |
Z2″×11.5 |
50 |
32 |
|
55 |
27.5 |
65 |
|
|
|
注：1.上述代号用于编织软管。 2.如需用于缠绕软管代号改为15612-xx-xx。 |
|||||||||
