代号 |
螺纹E |
软管 |
|
尺寸 |
||||
|
|
|
公称内径 |
标号 |
|
A |
d |
D |
H |
|
72011-02-03 |
G1/8″×28 |
5 |
03 |
|
18 |
9.9 |
24 |
16 |
|
72011-02-04 |
G1/8″×28 |
6 |
04 |
|
18.5 |
9.9 |
24 |
16 |
|
72011-04-03 |
G1/4″×19 |
5 |
03 |
|
19 |
13.3 |
24 |
15 |
|
72011-04-04 |
G1/4″×19 |
6 |
04 |
|
19.5 |
13.3 |
24 |
15 |
|
72011-04-05 |
G1/4″×19 |
8 |
05 |
|
19.5 |
13.3 |
24 |
15 |
|
72011-04-06 |
G1/4″×19 |
10 |
06 |
|
19.5 |
13.3 |
24 |
15 |
|
72011-06-04 |
G3/8″×19 |
6 |
04 |
|
22 |
16.7 |
29 |
20 |
|
72011-06-05 |
G3/8″×19 |
8 |
05 |
|
22 |
16.7 |
29 |
20 |
|
72011-06-06 |
G3/8″×19 |
10 |
06 |
|
22 |
16.7 |
29 |
20 |
|
72011-06-08 |
G3/8″×19 |
12 |
08 |
|
23 |
16.7 |
29 |
20 |
|
72011-08-05 |
G1/2″×14 |
8 |
05 |
|
27.5 |
21 |
38 |
25 |
|
72011-08-06 |
G1/2″×14 |
10 |
06 |
|
27.5 |
21 |
38 |
25 |
|
72011-08-08 |
G1/2″×14 |
12 |
08 |
|
28 |
21 |
38 |
25 |
|
72011-08-10 |
G1/2″×14 |
16 |
10 |
|
29 |
21 |
38 |
25 |
|
72011-10-10 |
G5/8″×14 |
16 |
10 |
|
28 |
23 |
40 |
27 |
|
72011-12-10 |
G3/4″×14 |
16 |
10 |
|
32 |
26.5 |
48 |
31 |
|
72011-12-12 |
G3/4″×14 |
20 |
12 |
|
32 |
26.5 |
48 |
31 |
|
72011-16-08 |
G1″×11 |
12 |
08 |
|
40 |
33.3 |
60 |
42 |
|
72011-16-12 |
G1″×11 |
20 |
12 |
|
40 |
33.3 |
60 |
42 |
|
72011-16-16 |
G1″×11 |
25 |
16 |
|
41 |
33.3 |
60 |
42 |
