90° ELBOW JIC MALE 74° CONE / BSP MALE O-RING

代号

PART NO.

螺 纹  THREAD

O形圈  O-RING

尺 寸  DIMENSIONS

E

F

F端

A

B

S1

S2

1JG9-04-02OG

7/16″×20

G1/8″×28

O011

24.5

26.2

11

14

1JG9-04-06OG

7/16″×20

G3/8″×19

O113

27.5

36.8

16

22

1JG9-04OG

7/16″×20

G1/4″×19

O111

26.6

31.3

14

19

1JG9-05-04OG

1/2″×20

G1/4″×19

O111

26.5

31.8

14

19

1JG9-05-06OG

1/2″×20

G3/8″×19

O113

27.5

35.8

16

22

1JG9-05-08OG

1/2″×20

G1/2″×14

O115

31.5

43.2

22

27

1JG9-06-04OG

9/16″×18

G1/4″×19

O111

26.9

31.3

14

19

1JG9-06-08OG

9/16″×18

G1/2″×14

O115

32.5

43.2

22

27

1JG9-06OG

9/16″×18

G3/8″×19

O113

28.5

35.8

16

22

1JG9-08-04OG

3/4″×16

G1/4″×19

O111

32

33.5

19

19

1JG9-08OG

3/4″×16

G1/2″×14

O115

34.8

43.2

22

27

1JG9-08-06OG

3/4″×16

G3/8″×19

O113

32

36.8

19

22

1JG9-08-12OG

3/4″×16

G3/4″×14

O119

37.9

49.3

27

32

1JG9-10-06OG

7/8″×14

G3/8″×19

O113

37.8

39.2

22

22

1JG9-10-08OG

7/8″×14

G1/2″×14

O115

37.8

43.2

22

27
